Why Your PlayStation 5 Needs an SSD Upgrade

Modern AAA games are consuming massive amounts of storage space, and the PlayStation 5’s internal drive fills up faster than ever. As physical game discs become a thing of the past, digital-only releases mean you’ll quickly run out of room without additional storage solutions. Without an upgrade, you’ll find yourself constantly uninstalling games to make space for new releases, then waiting through lengthy redownload times when you want to revisit them.

The good news is that expanding your PS5 storage with an M.2 SSD is straightforward, cost-effective, and safe. Installing a compatible drive won’t void your warranty as long as you handle the process carefully and avoid physical damage to your console. A quality M.2 SSD ensures you can build a robust game library and play the latest titles without storage anxiety.

Tools and Requirements You’ll Need

tools screwdriver hands workspace
Photo by Erinada Valpurgieva

Before you begin, gather the following items: a Phillips screwdriver (size #1), your chosen PCIe 4.0 x4 NVMe SSD with at least 5,500 MB/s sequential read speed, and an appropriate heatsink (either built-in or purchased separately). Popular options include drives like the WD Black SN850X for premium performance or the WD Blue SN5100 for budget-conscious gamers. Make sure your heatsink doesn’t exceed the PlayStation 5’s maximum thickness requirement of 0.44 inches (11.25 mm). Having a quality drive with proper warranty coverage protects your investment for years to come.

Step 1: Prepare Your Console Safely

Start by disconnecting both the HDMI cable and power adapter from your PlayStation 5. If you’re using the factory stand, remove it first. Place the console horizontally on a flat, clean surface to minimize the risk of accidental drops or scratches. Use an anti-static mat, cardboard, or plain paper underneath to protect the finish. Avoid soft fabrics like microfiber cloths or towels, which can generate static electricity that might damage internal components.

Step 2: Access the Console’s Interior

Touch a grounded metal object to discharge any static electricity from your body. Position your PS5 so the PlayStation logo faces downward and the rear ports point directly toward you. Firmly grip the console with one hand, then locate the right-bottom corner of the top cover. Gently lift it upward while sliding it to the left simultaneously. For PS5 Slim and Pro models, grip the smaller cover’s top edge and pull upward until you hear a subtle pop, indicating the internal clips have released.

Step 3: Remove the Expansion Slot Cover

Using your Phillips screwdriver, carefully remove the single screw securing the metallic expansion slot cover. Lift and set aside this cover to expose the M.2 SSD expansion slot beneath. This protective cover shields the slot during normal use, so handle it gently to avoid bending or scratching it.

Step 4: Prepare the Expansion Slot

Remove the screw and spacer currently installed in the expansion slot. Check your SSD’s form factor, which will be one of these sizes: 2230, 2242, 2260, 2280, or 22110. The PlayStation 5 supports all these dimensions. Move the spacer to the slot position that matches your drive’s length. This ensures proper alignment and prevents the drive from shifting during installation.

Step 5: Install Your M.2 SSD

Align the notches on your SSD with the connector slot on your PlayStation 5. Tilt the drive at a 30-degree angle and gently insert it into the M.2 connector. Once seated, press down firmly with your thumb until it sits flush. Secure it using the screw you removed earlier, tightening it snugly without excessive force, which could damage the drive or slot. Quality SSD manufacturers design their products for easy installation, so this step should feel straightforward.

Step 6: Install the Heatsink

SSD heatsink installation close up
Photo by Sergey Kuznetsov

If your SSD doesn’t have a factory heatsink, you’ll need to purchase an aftermarket one separately. Options like aluminum heatsinks designed specifically for PlayStation 5 ensure proper heat dissipation. Tilt the heatsink at the same 30-degree angle and align its notches with the corresponding space above the SSD. Insert it so it sits flush over the drive, apply light downward pressure with one finger, and tighten the mounting screw. Reinstall the expansion slot cover and the main console cover.

Step 7: Format and Finish

Reconnect your HDMI cable and power adapter, then turn on your PlayStation 5. The console will automatically detect your new SSD and prompt you to format it. Follow the on-screen instructions to complete the formatting process. Once finished, your expanded storage is ready for game installations and data storage.

With your new SSD installed and formatted, you’re free from storage limitations and can enjoy the full PS5 library without constantly managing space.
